1. Product Description
KRAFTMAX Heavy Duty Monograde Engine Oil Series is formulated from high-quality mineral base oils and advanced additive technology to provide reliable protection in a wide range of diesel engines operating under severe conditions. Available in multiple SAE grades, the series covers both winter (W) and summer viscosity ranges, meeting the needs of varied climates and applications.
2. Key Benefits
-
Economical performance for legacy diesel and gasoline engines
-
Excellent wear protection for engine components under severe load
-
High oxidation and thermal stability for acceptable oil life
-
Corrosion and rust protection
-
Reliable low-temperature start-up performance (winter grades)
-
Thick oil film for high-temperature protection (high-viscosity grades)
3. Applications
• Heavy duty diesel engines in trucks and buses
• Agricultural tractors and equipment
• Construction and mining machinery
• Stationary diesel engines and generators
• Small marine diesel engines where API CD/SG is specified
Not recommended for large marine engines operating on heavy fuel oil or where specific marine OEM approvals are required.
4.Performance Standards and Approvals
API CD/SG
5. Typical Technical Properties
|
Property |
|
|
|
|
|
|
|
Grades |
10W |
30 |
40 |
50 |
60 |
70 |
|
Density @ 15.6°C, g/ml, ASTM D4052 |
0.870 |
0.875 |
0.875 |
0.880 |
0.890 |
0.893 |
|
Kinematic Viscosity @ 40°C, mm2/s, ASTM D445 |
32 |
100 |
140 |
200 |
240 |
320 |
|
Kinematic Viscosity @ 100°C, mm2/s, ASTM D445 |
9,3 – 12,5 |
9,3 – 12,5 |
12,5 – 16,3 |
16,3 – 21,9 |
21,9 – 26,1 |
26,1 – 30,0 |
|
Viscosity Index, ASTM D2270, Min. |
95 |
95 |
95 |
95 |
90 |
90 |
|
Flash Point, COC, °C, ASTM D92, Min. |
210 |
220 |
230 |
235 |
240 |
220 |
|
Pour Point, °C, ASTM D97, Max. |
-30 |
-28 |
-28 |
-25 |
-20 |
-15 |
|
Total Base Number, mgKOH/g, ASTM D2896, Min. |
4,0 |
4,0 |
4,8 |
4,8 |
4,8 |
4,8 |
Disclaimer: The typical properties listed above represent average values and may vary within acceptable manufacturing tolerances. This information does not constitute a specification.
6. Packaging Options
Available in: 1L, 4L, 5L, 10 L pail, 20L pail, 55L drum, 200-208L barrel, 1000L IBC
Private label and bulk delivery options available on request.
7. Storage & Handling
- Store between 0°C and 40°C in dry, well-ventilated conditions
- Avoid direct sunlight and ignition sources
- Shelf life: 5 years in original sealed packaging
8. Health & Safety
Refer to the Material Safety Data Sheet (MSDS) for complete guidance on handling, disposal, and safety precautions.
Note: The information provided is based on current knowledge and experience. It does not constitute a legally binding assurance of specific properties.
